SINOTIMER TM919H-3 24V 16A DIN Rail 4 Pins Voltage Output Digital Switch Timer Automatic Cycle Timing Controller

The SINOTIMER TM919H-3 is a digital switch timer designed for automatic cycle timing control. It is suitable for home use, allowing users to program up to 16 on/off settings per day.

• Product Type: Digital Switch Timer
• Compatibility: 24V Digital Timing Controller
• Material: Not specified
• Power Supply: 85~265V, 220V, 110V, 12V, 24V, 5V 50/60Hz
• Capacity: 16A
• Timing Range: 1 minute to 168 hours
• Programmable Settings: 16 on/off programs per day, 15 combinations per week
• Power Consumption: Less than 5VA
• Power Off Time: 90 days
• Average Error: Less than 2 seconds/day
• Temperature Range: -10 to 50 degrees Celsius
• Display: Easy to read LCD display with LED indicator light
• Battery: Replaceable CR2032 battery for memory backup
• Mounting: Designed for 35mm DIN rail installation
• Manual Control: Repeating program with manual on/off setting
