Waveshare RPi IR-CUT Camera Module, Support Night Vision, Better Image in Both Day and Night

Name: Waveshare RPi IR-CUT Camera Module, Support Night Vision, Better Image in Both Day and Night
Brand: Waveshare
SKU: ZY15879528
Price: 569.00 ZAR
Availability: InStock

R 569.00

Sale Sold out

FREE DELIVERY on all orders.

hurry! almost sold out...

FREE Shipping

FREE SHIPPING on all orders. Fully Insured.

Handling time 1 - 3 working days. (PMC has to process your order and put all your items through its strict quality-control tests.)

Transit time 7 - 15 working days.

Get It Now, Pay Later

Pay using Mobicred. Simply choose Peach Payment >> Mobicred at checkout, and we’ll ship it once the order is approved.

Return Guarantee

For whatever reason if you are unsatisfied with your order within 7 days you can return it to us in new condition for a refund minus the shipping charges.

Payment & Security

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Missing/Wrong Items Guarantee

If you receive a parcel with missing/incorrect/secondary packing items, please contact us within 7 days of delivery and provide the relevant proof. PMC will make compensation based on the damage situation.

Features
1. Raspberry Pi Camera, supports all revisions of Pi
2. Embedded detachable IR-CUT filter to eliminate color distortion in daylight
3. Equipped with infrared LED to support night vision
4. 5 million pixel OV5647 sensor
5. Adjustable focal length
6. Camera specifications
- CCD size: 1/4 inch
- Aperture (F): 1.8
- Focal length: 3.6mm
- Viewing angle (diagonal): 75.7 degrees
- Sensor best resolution: 1080p
7. 4 screw holes
- for accessories
- Provide 3.3V power output
- Support for connecting infrared LEDs and / or fill flash LEDs
8. Size: 31mm × 32mm

Note: To use the camera on Raspberry Pi Zero / Zero W / Zero WH, you need to purchase a specific line: Raspberry Pi Zero v1.3 camera line

Package Contents
1. RPi IR-CUT camera x1
2. Infrared LED board (B) x2
3. 15-pin FFC (relative side contact) x1
